Features and Benefits
_X000D_
_X000D_ - Rugged Deprendability, High Quality and Innovation Make Cummins Onan Marine Generator in Marine Generator Design and Development, Providing Performance You Rely On. ™
_X000D_ - The Digital QD (Quiet Diesel) Series Models Are The First Marine Generator Sets with Self-Monitoring Capability and Network Communication.
_X000D_ -The Optional Cummins onan Digital Display Provides User-Fiander-Fiagnostics Inclument Extensive Engine and Alternator Information, Self-Deagnostic Features and Text Display.
_X000D_ - The Cummins Onan Marine Generators with Advanced Design and Development Processes Use Technology to Lower Sound and Vibration. Out
_X000D_ Sound shields minima noise and deliver better sound Quality. The Optimized Mounting System Greatly Reduces Vibration.
_X000D_ - Certified to U.S. Environmental Protection Agency (EPA) Emission Standards (60 Hz Models only).
_X000D_ - Cummins Onan Marine Generators have the Largest Worldwide Certified Distributor/Dealer Support Network in the Industry with the 70 Years of Marine Experience.
_X000D_
_X000D_Standard Features
_X000D_ - Advanced Digital Electronic Control Providing Extensive Diagnostic Capability
_X000D_ - Shutdown with Diagnostic Indicator Light for: High Engine Coolant Temperature, High Exhaust Temperature, Low Oil Pressure, Over Speed/Voltage, Starter Overcrank, No Raw Water Flow
_X000D_ -Start-Run-Stop Switch with Glow Plug Preheat and Fuel Pump Priming Modes for Easy Starting; Run Light and Diagnostic Indicator Light
_X000D_ - Start Function Has Automatic Glow Plug Preheat for Cleaner Starting
_X000D_ - Engine Starter with Automatic Start Disconnect
_X000D_ - Electronic Governor Allows The Generator Set to Maintain Isochronous Frequency Control and Close Voltage Regulation to Provide Quality Power For Digital Appliance and Computers
_X000D_ - Single Phase Ac Alternator with Single Or Dual Voltages, Brushless
_X000D_ - Digital Voltage Regulator Integral With Control
_X000D_ - 12 V DC Electric System with Battery Charging, Negative Ground
_X000D_ - DC Control Console Mounted with Isolation and DC Protection Circuit Breakers
_X000D_ - Electric Fuel Transfer Pump for Priming and Lift Capability
_X000D_ - Freshwater Cooling System with Heat Exchanger, Expansion Tank and Coolant Recovery System
_X000D_ - Water Coled Exhaust Mixing Elbow
_X000D_ - Gear-Driven Raw Water Pump
_X000D_ - AC Mainline Circuit Breaker
_X000D_ - Running Time Meter
_X000D_ - Air Intake Silencer
_X000D_ - Captive Focalized Mounting Systems with Vibration isolators
_X000D_ - Full Flow Lube Oil Filter
_X000D_ - Oil Drain and Hose Extension
_X000D_ - Electric Fuel Shut-Off Via Electronic Governing Actuator
_X000D_ - Fuel Filter/Water Separator
_X000D_ - DRIP PAN Base Capable of Containing All Generator Set Fluids
_X000D_ - External Mount Tabs Allow Flexible Mounting Arrangement
_X000D_ - Bulk Head Type Connections for Ease of Installation Include Fuel in, Fuel Out, Battery, Raw Water inlet, Wet Exhaust, Generator Set Ground (Vessel Bond)
_X000D_ - Single Point Lifting Bracket For Ease of Installation
_X000D_ - Plug-in Watertight Connector for Optional Remote Control
_X000D_ - Closeed Crankcase Breather Re-Circulation to Elminate Engine Room Contamination
_X000D_ - coolant overflow bottle to easily maintain coolant level
_X000D_ - Fire Extinguisher Access Port
_X000D_ - Factory Load Tested
_X000D_ - Five Year Limited Warranty
_X000D_
_X000D_Engine Details
_X000D_Design:4-Cycle, IDI Water-Coolled Diesel
_X000D_Cylinders:3
_X000D_ BORE: 78 mm (3.07 in)
_X000D_Stroke:78.4 mm (3.09 in)
_X000D_Displacement:1123 cm3 (68.58 in3)
_X000D_Compression Ratio:24:1
_X000D_Max Fuel Lift:1.22 m (4 FT)
_X000D_Lube Oil Capacity:4.0 L (4.2 QT)
_X000D_Coolant capacity:4.0 L (4.2 QT)
_X000D_Coolant flow rate:50 Hz: 15.9 L/Min (4.2 gal/min);
_X000D_60 Hz:18.9 L/Min (5.0 gal/min)
_X000D_Raw Water Flow Rate:
_X000D_ 50 Hz: 18.9 l/min (5.0 gal/min);
_X000D_ 60 Hz: 22.7 l/min (6.0 gal/min)
_X000D_Starting System:Remote 3-wire, 12 V Starting Battery,
_X000D_ 12 V 70 AH, 500 CCA; AT -18 ° C (0 ° F) Minimum, 24 V optional
_X000D_Power (Max):SAEJ1995
_X000D_ 50 Hz horse 1500 rpm 10.3 kW (13.8 hp)
_X000D_ 60 Hz AT 1800 RPM 12.4 KW (16.6 hp)
_X000D_Fuel Injection Pump:Bosch PFR-MD Mini
_X000D_Combustion Chamber:Spherical, Three Vortex Combustion System
_X000D_Max Raw Water Lift:1.22 m (4 FT)
