Features and Benefits
_X000D_
_X000D_ • Rugged Deprendability, High Quality and Innovation Make Cummins Onan Marine Generator in Marine Generator Design and Development, Providing Performance You Rely On. ™
_X000D_ • The Digital QD (Quiet Diesel) Series Models Are The First Marine Generator Sets with Self-Monitoring Capability and Network Communication.
_X000D_ • The Optional Cummins onan Digital Display Provides User-Fiander-Fiagnostics Inclument Extensive Engine and Alternator Information, Self-Diagnostic Features and Text Display.
_X000D_ • The Cummins Onan Marine Generators with the Development Processes Us Technology to Lower Sound and Vibration. Our sound shields minima noise and deliver better sound Quality. The Optimized Mounting System Greatly Reduces Vibration.
_X000D_ • Certified to U.S. Environmental Protection Agency (EPA) Emission Standards (60 Hz Models only).
_X000D_ • Cummins Onan Marine Generators have the Largest Worldwide Certified Distributor/Dealer Support Network in the Industry with More Tha 70 Years of Experience.
_X000D_
_X000D_Standard Features
_X000D_
_X000D_ • Advanced Digital Electronic Control Providing Extensive Diagnostic Capability
_X000D_ • Shutdown with Diagnostic Indicator Light for: High Engine Coolant Temperature, High Exhaust Temperature, Low Oil Pressure, Over Speed/Voltage, Starter Overcrank, No Raw Water Flow
_X000D_ • Start-Run-Stop Switch with Glow Plug Preheat and Fuel Pump Priming Modes for Easy Starting; Run Light and Diagnostic Indicator Light
_X000D_ • Start Function Has Automatic Glow Plug preheat Providing Better, Cleaner Starting
_X000D_ • Engine Starter with Automatic Start Disconnect
_X000D_ • Electronic Governor Allows The Generator Set to Maintain Isochronous Frequency Control and Close Voltage Regulation to Provide Quality Power For Digital Appliance and Computers
_X000D_ Single Phase Ac alternator with single or dual volts, Brushless
_X000D_ • Digital Voltage Regulator Integral with Control
_X000D_ • 12 V DC Electric System with Battery Charging, Negative Ground
_X000D_ • Electric Fuel Transfer Pump for Priming and Lift Capability
_X000D_ • DC Control Console Mounted with Isolation and DC Protection Circuit Breakers
_X000D_ • Freshwater Cooling System with Heat Exchanger, Expansion Tank and Coolant Recovery System
_X000D_ • Water Coled Exhaust Mixing Elbow
_X000D_ • Gear-Driven Raw Water Pump
_X000D_ • AC Mainline Circuit Breaker
_X000D_ Running Time Meter
_X000D_ • Air Intake Silencer
_X000D_ • Captive Focalized Mounting Systems with Vibration isolators
_X000D_ • Full Flow Lube Oil Filter
_X000D_ • Oil Drain and Hose Extension
_X000D_ • Electric Fuel Shut-Off Via Electronic Governing Actuator
_X000D_ • Fuel Filter/Water Separator
_X000D_ • DRIP PAN Base Capable of Continger All Generator Set Fluids
_X000D_ • Bulk Head Type Connections for Ease of Installation Include Fuel in Fuel Out, Battery, Raw Water inlet, Wet Exhaust, Generator Set Ground (Vessel Bond)
_X000D_ • Single Point Lifting Bracket For Ease of Installation
_X000D_ • Plug-in Watertight Connector for Optional Remote Control
_X000D_ • Closeed Crankcase Breather Re-Circulation to Elminate Engine Room Contamination
_X000D_ • Coolant Overflow Bottle to Easily Mainaine Coolant Level
_X000D_ • Fire Extinguisher Access Port
_X000D_ • Factory Load Tested
_X000D_ • Five Year Limited Warranty
_X000D_
_X000D_Engine Details
_X000D_
_X000D_Design:4-Cycle, Water-Coolled Diesel
_X000D_Cylinders: 4
_X000D_BORE:87 mm (3.43 in)
_X000D_Stroke:102.4 mm (4.03 in)
_X000D_Displacement:2434 cm3 (148.47 in 3)
_X000D_Compression Ratio:23.2:1
_X000D_Max Fuel Lift:1.22 m (4 FT)
_X000D_Lube Oil Capacity:7.6 L (8 QT)
_X000D_Coolant capacity:7.6 L (8 QT)
_X000D_Coolant flow rate:
_X000D_ 50 Hz: 37.9 l/min (10.0 gal/min);
_X000D_ 60 Hz: 53.0 L/Min (14.0 Gal/Min)
_X000D_Raw Water Flow Rate:50 Hz: 27 l/min (7.0 gal/min);
_X000D_ 60 Hz: 34.1 L/Min (9.0 Gal/Min)
_X000D_Starting System:Remote 3-wire, 12 V Starting Battery Required, 95 AH, 625 CCA; 24 V optional
_X000D_Power (Max): SAEJ1995
_X000D_ 50 Hz AT 1500 RPM 24.5 KW (32.8 HP)
_X000D_ 60 Hz AT 1800 RPM 27.6 KW (37.0 HP)
_X000D_Fuel Injection Pump:Bosch PFR-M Mini
_X000D_Combustion Chamber:Spherical, Three Vortex Combustion System
_X000D_Max Raw Water Lift:1.22 m (4 FT)
