Features and Benefits
_X000D_
_X000D_ • Rugged Deprendability, High Quality and Innovation Make Cummins Onan Marine Generator in Marine Generator Design and Development, Providing Performance You Rely On. ™
_X000D_ • The Digital QD (Quiet Diesel) Series Models Are The First Marine Generator Sets with Self-Monitoring Capability and Network Communication.
_X000D_ • The Optional Cummins onan Digital Display Provides User-Fiander-Fiagnostics Inclument Extensive Engine and Alternator Information, Self-Diagnostic Features and Text Display.
_X000D_ • The Cummins Onan Marine Generators with Advanced Design and Development Processes Use Technology to Lower Sound and Vibration.
_X000D_ Our sound shields minima noise and deliver better sound Quality. The Optimized Mounting System Greatly Reduces Vibration.
_X000D_ • Certified to U.S. Environmental Protection Agency (EPA) Emission Standards (60 Hz Models only).
_X000D_ • Cummins Onan Marine Generators have the Largest Worldwide Certified Distributor/Dealer Support Network in the Industry with More Tha 70 Years of Experience.
_X000D_
_X000D_Standard Features
_X000D_
_X000D_ • Advanced Digital Electronic Control Providing Extensive Diagnostic Capability
_X000D_ • Shutdown with Diagnostic Indicator Light for: High Engine Coolant Temperature, High Exhaust Temperature, Low Oil Pressure, Over Speed/Voltage, Starter Overcrank, No Raw Water Flow
_X000D_ • Start-Run-Stop Switch with Glow Plug Preheat and Fuel Pump Priming Modes for Easy Starting; Run Light and Diagnostic Indicator Light
_X000D_ • Start Function Has Automatic Glow Plug preheat Providing Better, Cleaner Starting
_X000D_ • Engine Starter with Automatic Start Disconnect
_X000D_ • Electronic Governor Allows The Generator Set to Maintain Isochronous Frequency Control and Close Voltage Regulation to Provide Quality Power For Digital Appliance and Computers
_X000D_ Single Phase Ac alternator with single or dual volts, Brushless
_X000D_ • Digital Voltage Regulator Integral with Control
_X000D_ • 12 V DC Electric System with Battery Charging, Negative Ground
_X000D_ • Electric Fuel Transfer Pump for Priming and Lift Capability
_X000D_ • DC Control Console Mounted with Isolation and DC Protection Circuit Breakers
_X000D_ • Freshwater Cooling System with Heat Exchanger, Expansion Tank and Coolant Recovery System
_X000D_ • Water Coled Exhaust Mixing Elbow
_X000D_ • Gear-Driven Raw Water Pump
_X000D_ • AC Mainline Circuit Breaker
_X000D_ Running Time Meter
_X000D_ • Air Intake Silencer
_X000D_ • Captive Focalized Mounting Systems with Vibration isolators
_X000D_ • Full Flow Lube Oil Filter
_X000D_ • Oil Drain and Hose Extension
_X000D_ • Electric Fuel Shut-Off Via Electronic Governing Actuator
_X000D_ • Fuel Filter/Water Separator
_X000D_ • DRIP PAN Base Capable of Continger All Generator Set Fluids
_X000D_ • Bulk Head Type Connections for Ease of Installation Include Fuel in Fuel Out, Battery, Raw Water inlet, Wet Exhaust, Generator Set Ground (Vessel Bond)
_X000D_ • Single Point Lifting Bracket For Ease of Installation
_X000D_ • Plug-in Watertight Connector for Optional Remote Control
_X000D_ • Closeed Crankcase Breather Re-Circulation to Elminate Engine Room Contamination
_X000D_ • Coolant Overflow Bottle to Easily Mainaine Coolant Level
_X000D_ • Fire Extinguisher Access Port
_X000D_ • Factory Load Tested
_X000D_ • Five Year Limited Warranty
_X000D_
_X000D_Engine Details
_X000D_Design:4-Cycle, Water-Coolled Diesel
_X000D_Cylinders:4
_X000D_BORE:83 mm (3.27 in)
_X000D_Stroke:92.4 mm (3.64 in)
_X000D_Displacement:1999 cm3 (122 in3) 50 Hz; 2434 cm 3 (148.5 in 3) 60 Hz
_X000D_Compression Ratio: 22.8:1
_X000D_Max Fuel Lift:1.22 m (4 FT)
_X000D_Lube Oil Capacity:7.6 L (8 QT)
_X000D_Coolant capacity:7.6 L (8 QT)
_X000D_Coolant flow rate:50 Hz: 37.9 l/min (10.0 gal/min);
_X000D_ 60 Hz: 53.0 L/Min (14.0 Gal/Min)
_X000D_Raw Water Flow Rate:50 Hz: 26.5 l/min (7.0 gal/min);
_X000D_ 60 Hz: 34.1 L/Min (9.0 Gal/Min)
_X000D_Starting System:Remote 3-Wire, 12 V Starting Batteryquired, 95 AH, 625 CCA; 24 V optional
_X000D_Power (Max):SAEJ1995
_X000D_ 50 Hz AT 1500 RPM 19.9 KW (26.7 hp)
_X000D_ 60 Hz AT 1800 RPM 27.6 KW (37.0 HP)
_X000D_Fuel Injection Pump:Bosch PFR-M Mini
_X000D_Combustion Chamber:Spherical, Three Vortex Combustion System
_X000D_Max Raw Water Lift:1.22 m (4 FT)
